Audytor HL

Building 3D modelling and heat load calculations.

Software designed for 3D computer modelling of buildings, as well as for computer aided calculations of heat load of individual rooms.

The program calculates (depending on the language version):

  • heat-transfer coefficients for walls, floors, roofs and flat roofs
  • heat losses for individual rooms
  • heat loss for the whole building
  • heat balance for the apartment building heating period
  • radiators selection





The program is used to support the calculation of the design heat load of rooms according to the standard PN-EN 12831 and the preliminary selection of radiators.

Program with a built-in mechanism for importing a building model from Autodesk® Revit®.

The Audytor HL 7.0 Pro program can be launched with the Audytor HL 6.9 Pro license number.

License owner of the Audytor HL 6.9 Pro program are welcome to download the newer version of the program.

Building 3D modelling and heat load calculations.

Software designed for 3D computer modelling of buildings, as well as for computer aided calculations of heat load of individual rooms.

Import and export of drawings in DWG format

The program has been equipped with the latest cooperation module with DWG and DXF files.

It allows among others:

  • Loading DXF and DWG drawings in the newest versions.
  • UNICODE text support for most characters to be displayed correctly.
  • Export of drawings in the following formats: DWG, DXF, PDF, SVG, CGM, HPHL, SWF.
  • Significantly faster display of complex drawings thanks to the simplified paint function.
  • A more realistic export of drawings to DXF and DWG files.
  • Saving raster drawings in DXF and DWG files.
  • More convenient management of drawing layers

Import of the building model from Revit 2020 - 2022

The function allows you to import a building model from RevitRevit has the ability to export a building model to the gbXML format. In order for the gbXML file to be properly adapted to the Audytor HL, you should use Audytor gbXML - the Revit plugin. Depending on the amount of data entered in Revit, the model may be almost full after the transfer. In the Audytor HL, only the data on the functions of rooms and the grouping of rooms can be supplemented. The imported building model can be verified using a three-dimensional preview.

  7.0 Pro 7.0 Basic 6.9 Pro 6.9 Basic
Import and export of drawings in DWG format
Import of the building model from Revit 2020 - 2022
Graphic creation of a building model
Heat transfer coefficient U for windows and door according to the standard PN-EN ISO 10077-1
Possibility to add your own linear thermal bridges to the database
Surfaces thermal bridges (linear and point) in multilayer partitions
Bonding and scaling drawings
Preview of the temperature compensation factor for homogeneous materials
Defining hygenic requirements for your own types of rooms
Creates a set of building materials in the building construction
Backup system of data files
Possibility to include a suspended ceiling in the thermal calculations of rooms
Creates a set of building components in the building construction
Creates a raport with a set of materials (building materials, building components, carpentry, radiators, manufacturers)
Heat load PN-EN 12831
Cooperation with programs from the SET family
Computing variables
Heat transfer coefficient PN-EN ISO 6946
Inhomogeneous partitions
The system default data inheritance
Correctness check of the model
Three-dimensional preview of the imported building model

Major changes in version 6.9 Pro

NOVELTY!

AUDYTOR HL 6.9 Pro can now load building models in gbXML format from Autodesk Revit!

  • the ability to load a three-dimensional building calculation model directly from the Revit 2016-2020 program using the free gbXML Audytor plugin,
  • mechanism for checking the correctness of the loaded building model and supplementing the data necessary to perform thermal calculations.



About the program

The calculation methodologies given in current standards and regulations are in many cases very complicated, often containing a lot of insignificant details, and are also full of errors. The many years of experience of our company and the software development team (the core of the company is made up of employees and graduates of the Institute of Heating and Ventilation at the Warsaw University of Technology) enabled the development of a program that on the one hand allows for thermal calculations in accordance with applicable regulations, on the other frees designers from the need for in-depth study often unclear regulations.



Our many years of experience have allowed us to eliminate many errors occurring in the regulations and to introduce additional extensions of calculation methods that increase the flexibility of the program.

The solutions used in the program (data inheritance system) make that despite complicated computational methods and a huge amount of information necessary to enter in order to perform calculations, the time necessary to prepare a project is not too long.



We have also equipped our program with an extensive error diagnosis system and interpretation of the results obtained.

All this combined with the intuitive and transparent data entry process means that the program is able to guide the designer through the calculations process.

To meet our clients' expectations and market needs, the Audytor HL program is constantly updated by us and adapted to current changes in regulations.

Possibility to add your own linear thermal bridges to the database

The program is equipped with a thermal bridges catalog according to PN-EN ISO 14683. This catalogue can be supplemented by user with additional thermal bridges.

Bonding and scaling drawings

HL programs and CH are equipped with the function of Graphic creation of a building model. This function gives you the opportunity to draw a building model. To simplify the action of drawing, you can load a drawing base into the program. The file being loaded can come from an external program for creating technical drawings (eg DWG), or from a scanned drawing (eg JPG). The scanned drawing can be divided into several files. Drawings scanned into several files usually do not keep the scale precisely enough. They can also be rotated relative to each other by a small number of degrees.

Drawing bonding allows you to quickly scale multiple scanned drawings (in different sizes and rotated) and bond them with one another.

Backup system of data files

The program has a mechanism that automatically creates a set of project backups (up to 8 files).

Data files are backed up every time data is saved, with the new files overwriting the older files so that at least one copy of the file from each stage of the project work is always kept.

This function will allow you to recover the project file even if its last versions are overwritten or damaged.

Possibility to include a suspended ceiling in the thermal calculations of rooms

The program allows to skip the space above the suspended ceiling during the thermal calculations of the room. This space will not be included in the internal volume.

Cooperation with programs from the SET family

After calculating the heat load, the results can be downloaded from CH family programs, eg Audytor CH. CH programs are used to graphically support the design of installations and to regulate existing central heating and chilled water installations. On the basis of the drawing of the installation and the devices selected by the user, the program selects radiators, pipe diameters, fittings and pre-settings of valves, pumps, gives total pressure loss in the installation etc.

Correctness check of the model

After 3D computer models of buildings have been created, designers can perform correctness check of entered building partitions.

Easy input of your design data into the computer

User's friendly 3D design editor assists designers in effective and fast data input.

Easy computer modelling of storeys of buildings

Thanks to the functionality of entering building base drawings, users can draw walls, windows, doors and floors with no requirement of precise manual dimensioning of all these components. Import of building base drawings is possible from DWG files, bitmaps or directly from scanning devices

Correctness check of the model

After 3D computer models of buildings have been created, designers can perform correctness check of entered building partitions.

Time saving

The concepts of data inheritance and default data will save users time and effort when entering individual building components.

Option for fast modification of parameters

Application of variables enables performing variant calculations.

Preliminary selection of radiators

Already at the stage of designing buildings, designers can assess the required dimensions of radiators in heating systems.

Assistance in preparation of technical documentation

Designers can prepare technical documentation for projects, basing on extensive overviews of materials, building partitions and selected radiators.

Technical requirements

The program runs under MS Windows (10, 11) 32bit and 64 bit.

The minimum hardware:

  • 1200 MHz processor,
  • 4 GB RAM,
  • 2 GB of free hard disk space,
  • A color monitor with a minimum screen resolution of 1024x768,
  • 500 MB free space on the hard drive,
  • Compatible graphics card with OpenGL 2.0 and higher: all new graphics cards on the market should meet the minimum hardware requirements;

Hardware requirements for the 3D editor

Vertical resolution requirements for the screen:
- minimum - 768 points,
- sufficient for comfortable work - 900 points,
- the most convenient - 1080 points.

Requirements for system font settings:
- Windows Vista, 7, 8 - fonts "100% smaller",
- Windows XP - "normal" fonts.

The computer should have a graphics card that supports OpenGL technology in the version:
- minimum 2.0,
- sufficient for comfortable work: 3.3 and higher.
